What's on the menu tonight? Movies, music or gaming? The JBL Bar 500 brings your movies to life with MultiBeam™ and Dolby Atmos® 3D surround sound. While PureVoice technology optimizes voice clarity to ensure you never miss a word. Feel the thrilling bass from the wireless 10" subwoofer. And with AirPlay, Alexa Multi-Room Music (MRM) and Chromecast built-in™, you've got over 300 easy streaming options to choose from, whether you want to dance or you're ready to relax. Whatever you're in the mood for, the JBL Bar 500's got you covered.
Power supply
100 - 240V AC, ~ 50/60Hz
Networked standby power
< 2.0 W
Operating temperature
0°C - 45 °C
Total speaker power output (Max @THD 1%)
590W
Soundbar output power (Max @THD 1%)
290W
Subwoofer output power (Max. @THD 1%)
300 W
Soundbar transducer
4x (46x90)mm racetrack drivers, 3x 0.75" (20mm) tweeters
Subwoofer transducer
10” (260mm)
Frequency response
35Hz - 20kHz (-6dB)
Audio inputs
1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)
Soundbar dimensions (W x H x D)
1017 x 56 x 103.5 mm
Subwoofer dimensions (W x H x D)
305 x 440.4 x 305 mm
Soundbar weight
2.8kg
Subwoofer weight
10 kg
Packaging dimensions (W x H x D)
1105 x 370 x 475 mm
Packaging Weight
16.2 kg
USB port
Type A
USB rating
5V DC, 0.5A
Supporting file format
MP3
MP3 codec
MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
MP3 sampling rate
16 - 48 kHz
MP3 bitrate
80 - 320 kpbs
Bluetooth version
5.0
Bluetooth profile
A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range
2400 MHz – 2483.5 MHz
Bluetooth transmitter power
<15 dBm (EIRP)
Wi-Fi network
IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range
2412 - 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power
< 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range
5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHz
5G Wi-Fi transmitter power
5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)
2.4G wireless transmitter frequency range
2406 - 2474MH
2.4G wireless transmitter power
<10dBm (EIRP)
HDMI video input
1
HDMI video output (with Enhanced Audio Return Channel, eARC)
1
HDMI HDCP version
2.3
HDR pass through
HDR10, Dolby Vision
